1 μm Fineness Vacuum Transformer Oil Purifier 12000 LPH Water
Removal
What is the Vacuum Transformer Oil Purifier?
The transformer oil filter machine is a mechanical device that
filters solid impurities, moisture, and gas in oil, improves oil
quality performance, and improves the insulation strength of
transformer oil.
Application of Sino-NSH VFD-200
It is mainly used for large-scale transmission and transformation
equipment above 110KV and the national main transformer grid,
on-site maintenance of transformers in large-scale substations,
rapid and advanced treatment of new oil, imported oil, and other
insulating oils, new oil, imported oil, transformer oil and
substation systems Vacuum filtration and purification treatment of
relatively expensive oils such as capacitor oil and refrigerating
machine oil.
Application Scenarios of the Transformer Oil Purification Machine
Insulating oil filtration machine is used in power plants, power
stations, power companies, metallurgy, petrochemical, railway, and
other industrial and mining enterprises to purify unqualified
electrical insulating oil. It can also be used for vacuum pumping
and vacuum drying of electrical equipment.
Sino-NSH Double-Stage Vacuum Oil Purifier Options
1. According to the needs of users, it can be equipped with PLC
intelligent control, touch screen operation, and dynamic display.
2. Optional online moisture detector.
3. The frequency converter is optional, and the flow rate can be
selected according to the needs.
4. Optional flow meter with accumulative function.
5. The structure of the whole machine can be made into mobile type,
fixed type, trailer type (half shaft or double shaft), fully
enclosed type, canopy type, canvas tent, and open type.
Parameter
| Parameters | Value | | |
| VFD-30 | VFD-50 | VFD-75 | VFD-100 | VFD-150 | VFD-200 | VFD-300 |
| Capacity, liters/hour | 1800 | 3000 | 4000 | 6000 | 9000 | 12000 | 18000 |
| Heating Power, kW | 24 | 30 | 48 | 60 | 90 | 120 | 150 |
| Total Power, kW | 29 | 36 | 56 | 69 | 100 | 132 | 170 |
| Power supply | Fully Customizable |
| Inlet Diameter, mm | 25 | 32 | 32 | 40 | 40 | 50 | 65 |
| Outlet Diameter, mm | 25 | 32 | 32 | 40 | 40 | 50 | 65 |
Dimensions
(without trailer) | length, mm | 1350 | 1500 | 1550 | 1900 | 2200 | 2400 | 2900 |
| width, mm | 1100 | 1200 | 1250 | 1400 | 1500 | 1600 | 1800 |
| height, mm | 1700 | 1750 | 1800 | 1800 | 1850 | 1900 | 2000 |
| Weight(without trailer), kg | 600 | 800 | 900 | 1150 | 1500 | 1700 | 2400 |
| Processed Oil Spec | Water Content, ppm | ≤5 |
Dielectric Strength, Kv | ≥75 |
| Filtration Fineness, um | ≤5( or 1-5 as needed ) |
Gas Content, % | ≤0.1 |
Our Service
1. 1 years warranty.
2. Provide customers with all technical drawings, materials of
equipment purchased, and long-term technical consultation for free.
3. Strictly according to customer needs, provide customers with the
best oil treatment solutions, and provide good performance
products.
4. Ensure that the equipment is provided with perfect processing
technology, perfect testing means, and equipment performance is
good.
Retrofitting Options
1. Fully automatic PlC touchable screen
2. Digital water content tester
3. Digital flow meter
4. Breakdown voltage tester
5. Particle count meter
Other Models Purifier Machines
| TF Series: |
| TF series oil filter is a filtration and dehydration unit with
thermal and vacuum processing, it's ideal for filtration and
dehydration of turbine oil, this unit can extend turbine oil life
by removing contaminates from oil, such as water, gas, and
particulates, improve the oil properties. |
| LV Series: |
| LV series oil filter is a dehydration and degassing unit with
thermal and vacuum processing, it's a multifunctional purifier that
can treat various kinds of lubricant oils. |
| FV Series: |
| LV series oil filter is a stainless steel machine with thermal and
vacuum processing, it's mainly used to improve the properties of
phosphate ester fire-resistant oil in generator sets. |
| GER Series: |
| Used oil regeneration system is suitable to regenerate used
internal-combustion engine oil including diesel engine oil,
gasoline engine oil, and used hydraulic oil, and other used
lubrication oil for machinery. |
| GED series: |
it is used to recycle all kinds of waste oil into base oil or
diesel oil with high quality.
|
